Here at Zhouxiang, we are proud to be among the self aligning welding rotator manufacturers and suppliers in China. By purchasing our self aligning multifunctional welding rotators, you shall experience unparalleled operational accuracy and enhanced productivity in your welding processes.
| Spec. | Max. load weight-kg | Suitable diameter of vessel(mm) | Dia. and width of the wheel/PU rollers-mm | Dia. and width of the wheel/Metal rollers-mm | Roller linear speed-m/h | Power of motor-kw |
|---|---|---|---|---|---|---|
| GLHZ-5 | 5000 | φ250-φ2300 | φ250*140 | 6-60 | 0.75 | |
| GLHZ-10 | 10000 | φ320-φ2800 | φ300*170 | 6-60 | 1.1 | |
| GLHZ-20 | 20000 | φ500-φ3500 | φ350*180 | 6-60 | 2.2 | |
| GLHZ-40 | 40000 | φ600-φ4200 | φ400*200 | 6-60 | 3 | |
| GLHZ-60 | 60000 | φ750-φ4800 | φ450*220 | 6-60 | 4 | |
| GLHZ-80 | 80000 | φ850-φ5000 | φ500*240 | 6-60 | 4 | |
| GLHZ-100 | 100000 | φ1000-φ5500 | φ500*260 | 6-60 | 5.5 | |
| GLHZ-150 | 150000 | φ1100-φ6000 | φ600*280 | 6-60 | 7.5 | |
| GLHZ-250 | 250000 | φ1200-φ7000 | φ700*300 | 6-60 | 2*5.5 | |
| GLHZ-500 | 500000 | φ1800-φ8000 | φ850*350 | 6-60 | 2*7.5 |
