Zhouxiang’s positioners for welding are based on new technologies and are built with careful detail to meet varying industrial and ergonomic requirements. Our offerings ensure maximum productivity during the processing of large structures and incorporate fine detail components.
Our cutting-edge welding positioner enhances efficiency and accuracy during welding. Simple to use, rugged, and fully adjustable—ideal for high-precision detailed work.
Worktable rotation employs frequency conversion for limitless speed control.
For tilting, it uses gear transmission, the forging process bestows durability and a long lifespan on the gear.
Operational efficiency is improved by optional remote control without wires.
It is possible to tilt from 0° to 120° which improves positioning.
There are concentric tick marks alongside T-type slots which are useful for work-piece mounting.
Compact design allows for semi-automatic and automatic welding versatility.
| Spec . | Rated load capacity-Kg | Rotating speed-rpm | Overturning angle-(°) | Size of working table-（mm） | Motor power（kw） | Motor power（kw） |
|---|---|---|---|---|---|---|
| Rotating | Overturning | |||||
| HBZ-1 | 100 | 0.35-3.5 | 0-90° | φ400 | 0.09 | 0.18 |
| HBZ-3 | 300 | 0.2-2 | 0-90° | φ600 | 0.37 | 0.37 |
| HBZ-6 | 600 | 0.09-0.9 | 0-90° | φ1000 | 0.75 | 0.75 |
| HBZ-10 | 1000 | 0.05-0.5 | 0-120° | φ1200 | 1.1 | 1.5 |
| HBZ-30 | 3000 | 0.05-0.5 | 0~120° | φ1400 | 1.5 | 1.5 |
| HBZ-50 | 5000 | 0.05-0.5 | 0~120° | φ1500 | 2.2 | 4 |
| HBZ-100 | 10000 | 0.017-0.17 | 0~120° | φ2000 | 3 | 5.5 |
| HBZ-200 | 20000 | 0.015-0.15 | 0~120° | φ2300 | 5.5 | 7.5 |
🔥Enhance your welding projects with our top of the line precision welding positioner! A must for each professional and welding enthusiast.
Here's what our customers have to say about Zhouxiang Welding Positioners:
Preserve Creativity by Keeping Abreast The Blog Has To Offer On The Latest Updates, Methods, Developments, And Ideas Relating to The Discipline.
Utilizing the wind’s energy has always been a mark of human creativity, But how do current wind towers and turbines function? These towering beauties placed around the world are...
Pipe welding calls for precision, expertise, and class-leading equipment to ensure high-quality outcomes. For pipe welders striving to perfect their craftsmanship, learning to utilize a positioner with the proper...
Increasingly around the world, changing to renewable energy has made wind power one of the easiest and most sustainabale options for achieving emission and clean energy goals. Wind power...
The development of welding rotators has made a huge impact on fabrication with regards to precision, efficiency, and even safety while working on cylindrical parts. In heavy industry, manufacturing...
Zhouxiang provides high-tech welding positioners for augmentations or new production lines. Visit our site for more details and ask for your customized quote now!
A: A welding positioner is a machine tool that is used to fix the workpiece for welding. It improves the welder’s effectiveness by rotating and tilting the workpiece to the optimal position for welds.
A: A weld positioner helps improve productivity by adjusting the workpieces to the optimal angles and heights, thereby reducing the manual adjustments to be made by the technician. This increases the speed of welding and saves time and cost.
A: Welding positioners are very effective in welding processes such as TIG and MIG welding and robotic welding systems. They are specially designed for pipe welds, fabrication, and any precise multi-angle weld applications.
A: A benchtop welding positioner has advantages, like, increased accuracy while working with small and medium sized parts, being compact, easy to use and providing stability during operation. It increases efficiency in optimizing the welding operations.
A: The welding positioner’s rotational speed, usually given in revolutions per minute (rpm), is one of the major factors impacting welding performance. Greater flexibility in achieving different rotation speeds leads to better control of the welding, which helps adapt using different materials and requirements of the workpiece.
A: As a matter of fact, many welding positioners do allow for the use of foot pedals for control, hence allowing the operator to control the rotation and inclination of workpieces hands-free. This additionally aids in improving the control and accuracy in welding operations.
A: Pipe welding positioners require having features like variable speed control, tilt control, advanced load capacity, as well as quality in their motor and speed settings. A combination of these will position you to assure that ideal capabilities for your specific welding scenarios are achieved.
A: Unlike other welding positioners that may also provide tilting capabilities, a welding turntable’s main purpose is to sequentially rotate workpieces for universal access to all sides for welding. Turntables are very suitable for jobs that require prefabricated components to be welded on 360 degrees.
A: New welding positioner kits usually come with one or more additional accessories that are meant to multifunctionally augment the positioner. This allows the user to weld in different conditions while maximizing efficiency for each operation.
