The Zhouxiang Column and Boom is equipped with advanced technology to ensure performance unmatched by other machines in the market. It is designed with advanced technology and a strong structure which provides accuracy and efficiency in welding with a high level of safety.
Learn the primary benefits of our column and boom welding machine which emphasizes sharp accuracy, effectiveness, and adaptability for industrial welding applications.
Offers fixed, rotating, and moving types to suit diverse operational needs.
Utilizes high-precision tempered parts and rack-and-gear systems.
Has cross sliders for accurate positioning of the torch in all planes.
Allows coordinated operation with welding power, rotators, and positioners for streamlined processes.
Integrates a fail-safe mechanism for the prevention of boom falls during elevation.
Includes service ladders and platforms, and allows remote controls with wireless options.
| Type | Heavy-duty | Heavy-duty | Heavy-duty | Middle-duty | Middle-duty | Light-duty |
|---|---|---|---|---|---|---|
| 8*6 | 5*6 4*5 | 5*6 4*5 | 3.5*5 3*4 | 3.5*5 3*4 | 2*2 | |
| Effective stroke of vertical boom-mm | 8000 | 5000 | 4000 | 3500 | 3000 | 2000 |
| Effective stroke of cross boom mm | 6000 | 6000 | 5000 | 5000 | 4000 | 2000 |
| Suitable diameter of cylinder-mm | 1000-8000 | 1000-5000 | 1000-4000 | 700-3500 | 700-3000 | 500-2000 |
| Rotating angle of the vertical boom | ¡À180¡ã | ±180° | ±180° | ±180° | ±180° | ±180°(by manual) |
| Up and down speed of cross boom-m/min | 0.9 | 1 | 1 | 1 | 1 | 0.3 |
| Expansion speed of cross boom-m/min | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 |
| Forward and backward speed of the trolley-m/min | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| The center distance of the trolley track-mm | 2308 | 1780 | 1780 | 1780 | 1500 | 900 |
Browse through the fine selection of welding manipulators offered for sale to increase precision, productivity, and efficiency while working on welding projects.
Zhouxiang values the reception of appreciation from our esteemed clients. Here is what they have to say:
Follow The Blog for New Strategies, Methods, Breakthroughs, and Perspectives Relevant to the Domain to Sustain Creativity.
Utilizing the wind’s energy has always been a mark of human creativity, But how do current wind towers and turbines function? These towering beauties placed around the world are...
Pipe welding calls for precision, expertise, and class-leading equipment to ensure high-quality outcomes. For pipe welders striving to perfect their craftsmanship, learning to utilize a positioner with the proper...
Increasingly around the world, changing to renewable energy has made wind power one of the easiest and most sustainabale options for achieving emission and clean energy goals. Wind power...
The development of welding rotators has made a huge impact on fabrication with regards to precision, efficiency, and even safety while working on cylindrical parts. In heavy industry, manufacturing...
Zhouxiang Column and Boom Welding Machine Automation Integration will change how you do business. Work faster, more accurately, and more safely. If you wish to see how Zhouxiang can power your success kindly request a quote using the button provided below.
A: A column and boom manipulator is a mechanized welding system which is made up of a vertical column and a horizontal hinged boom which makes movement and positioning of the welding equipment easy, and is normally used for different weld processes like TIG and MIG.
A: The column and boom system improves automation of the welding process by facilitating proportional control over the welding head, enhancing the overall operational efficiency and uniformity in weld quality, allowing for both longitudinal and circular welds to be executed.
A: Compared to other conventional welding machines, one of the most interesting Characteristics of Boom welding is that the productivity is higher, the operators required are lesser, Safety measures are easier to maintain, the quality of welds is higher; All of which enhance modern fabrication techniques.
A: Absolutely, the column and boom manipulators are adaptable and can be configured for several weld processes such as TIG, MIG, and submerged arc welding, thus increasing flexibility in the welding operations.
A: The weld head is the main part in column and boom systems as it removes waste byproducts, provides the necessary welding current, and carries out filler material as well as gas to maintain the temperature, thus ensuring flawless and accurate welds.
A: The application of automation yields notable advantages in the performance of the welding column, enabling programmable motions and movements, elimination of human error, and increased repetitive performance of all operations, thus improving productivity and lowering deviation.
A: Certainly, column and boom systems are structurally adaptable and robust to be used for heavy-duty applications, suitable for large parts and assuring strong welds regardless of the materials and thicknesses.
A: The range of materials that can be welded using column and boom equipment includes carbon steel, and aluminum, giving them a broad flexibility regarding different industrial applications.
A: A column and boom systems integrates with cladding processes by drviving the manipulator for precise and accurate striated movement for application of protective coatings on base materials using various welding techniques.
A: It is critical to take into account the processes of welds that are to be executed, the items that are to be joined together, their dimensions and weight, and the amount of automation required when selecting a column and boom manipulator for a welding project in order to promote productivity and effectiveness.
